Elements of an AgentType Subclass

Other introductory notebooks have used AgentType subclasses like PerfForesightConsumerType and IndShockConsumerType to show HARK’s representation of microeconomic agents. The basic functionality for AgentTypes is covered in other notebooks, including setting parameters, solving the model, and generating simulated outcomes. But those notebooks don’t tell you much about how an AgentType subclass works or what goes into one; that’s what we’ll cover here!

Time-Varying and Time-Invariant Solver Inputs

When it’s time to solve a model, HARK reads in the required inputs from the attributes of the AgentType instance and/or its parameters dictionary. But some parameters are time-invariant– constant across all periods of the model– while others might vary across periods and are time-varying. The latter kind of solver inputs should consist of a list of length T_cycle, with one element per period, while the former are just single objects.

HARK differentiates between the two by looking at the attributes time_vary and time_inv, which are lists of strings naming the time-varying and time-invariant solver inputs. These are instance-specific lists– making changes to time_vary on one instance of an AgentType subclass won’t affect the properties of another instance of that class.

At the class level, time_vary and time_inv default to the class attributes time_vary_ and time_inv_ at instantiation (note the extra underscore at the end). Each AgentType subclass should specify these lists, naming the appropriate solver inputs in each category for the default parameters.

Almost all model inputs can be freely moved between time_vary and time_inv, as long as the parameter values are changed appropriately as well. In some cases, there might not be a meaningful interpretation to a model object being time (in)variant (e.g., something that is supposed to represent a universal constant somehow varying with a particular agent’s age), but that doesn’t prevent HARK from solving the model.

The primary exception (which we hope to fix in the future) is CRRA, the coefficient of relative risk aversion with respect to consumption. HARK’s solvers assume that risk aversion is constant across all periods and incorporate this into their math.

Moreover, the original/legacy simulation system will not behave properly if model objects are moved between time_vary and time_inv. However, the new simulation machinery (using symulate, etc) does automatically handle changes to time_vary and time_inv. In some cases, you might need to add a + to an object’s declaration in the model file if it is time-invariant by default but “offset” in time if interpreted as time-varying.

Taking it One Day at a Time: solve_one_period

Each AgentType subclass needs a function that solves the “one period problem” for that model. This function takes as arguments a representation of next period’s model solution and all of the information needed to solve the period \(t\) problem, and returns a single object representing the solution to the period \(t\) problem.

This function is stored on each AgentType instance in the solve_one_period attribute. When an instance of an AgentType subclass is created, solve_one_period is set based on the value in default_["solver"], a class attribute with model defaults (see here for more about model defaults). The solve_one_period function can be changed after instantiation on an instance-by-instance basis– maybe you have a different way of solving the same model!

The argument name for the succeeding period’s solution must be solution_next. By convention, it is the first argument to a solve_one_period function, but this is not required. Don’t put solution_next in time_vary (nor time_inv); it’s a special name that HARK uses internally.

All other argument names should refer to attributes of the AgentType instance.

Representing the Model’s Solution

What does it mean for an object to represent the solution to one period of a model? It completely depends on the context!

In general, HARK models have special object classes for representing the model solution. These are usually just “container classes” that hold named attributes of the solution, but they might have methods built into them. In principle, the representation of one period’s solution could be a single policy function, or a dictionary of solution elements (rather than a simple class).

As an example, many HARK models use the class ConsumerSolution from HARK.ConsumptionSaving.IndShockConsumerType to represent the solution to one period. This class specifies that it has the following attributes (all of which are optional):

• cFunc : The consumption function over the state space at decision-time

• vFunc : The value function over the state space at decision-time

• vPfunc : The marginal value (w.r.t market resources) function over the state space at decision-time; the P is for “prime”

• vPPfunc : The marginal marginal value (w.r.t market resources) function over the state space at decision-time

• mNrmMin : The smallest “legal” value for normalized market resources at decision-time

• hNrm : Normalized “human wealth”– the PDV of future non-capital income

• MPCmin : Lower bound of the marginal propensity to consume from market resources as \(m_t\) goes to infinity

• MPCmax : Upper bound of the marginal propensity to consume from market resources as \(m_t\) approaches mNrmMin

ConsumerSolution has one method, append_solution, which is used in ConsMarkovModel to add a discrete-state-conditional solution to the existing solution.

Perhaps You Had Better Start From the End: solution_terminal

The meaning of the “succeeding period’s solution” is usually pretty clear, but what about when the solve method first starts– how can it pull down the “next” period’s solution if it’s trying to solve the final period?

HARK deals with this complication by having a special attribute called solution_terminal. This object should be a representation of the solution to the one-period problem that can be passed as solution_next to the solve_one_period function. It is referenced by the solve method only when trying to solve the very first period– er, the last period.

The object in solution_terminal can be built with a constructor function. It is also possible to pass solution_terminal as an argument when instantiating an AgentType, or to manually set it later.

In many models, the solution to the period \(T\) problem is trivial. E.g. for an IndShockConsumerType, the solution to the terminal period is, “consume all market resources, and get value equal to the utility of doing that.” The constructor for solution_terminal builds a ConsumerSolution instance that represents this trivial solution, and then the main loop of the solve method takes it from there.

In other models, even period \(T\) isn’t trivial to solve, and there’s meaningful work to be done. For example, in the presence of a “warm glow” bequest motive, an agent who knows he will die at the end of this period must choose how to allocate his resources between consumption and their bequest. The ordinary solve_one_period function can be used to solve the period \(T\) problem… but it still needs something to be passed to it as solution_next. Thus in the ConsBequestModel, solution_terminal is essentially an “empty” solution for a non-existent period \(T+1\) solution. It exists in the computer, but is not meaningfully used when solving period \(T\) (because there is zero chance of survival).

The distinction between these two interpretations of a “terminal” solution object is indicated by the attribute pseudo_terminal:

• pseudo_terminal=False means that the object in solution_terminal really is the period \(T\) solution; agents can actually reach this period and act on its policy function

• pseudo_terminal=True means that the object in solution_terminal is a “fake” solution to a non-existent period; it exists only to allow the solver to start and is not really part of the agent’s “solution” to their model.

Simulation Variable Names

HARK has a built-in system for simulating model outcomes– two systems, in fact– and there are some AgentType subclass attributes that should be set to enable this.

Nothing’s Shocking: Random Variables and Distributions

When an AgentType instance is simulated, random variables are drawn from distributions as shocks.

The names of shock variables must be named (as a list of strings) in the class attribute shock_vars_. For example, the IndShockConsumerType specifies that shock_vars_ = ['PermShk', 'TranShk'], meaning that permanent and transitory income shocks will occur.

The distributions from which shocks are drawn should be named in the class attribute distributions (as a list of strings). For example, a PerfForesightConsumerType has distributions = ['kNrmInitDstn', 'pLvlInitDstn'], and IndShockConsumerType adds "IncShkDstn", "PermShkDstn", and "TranShkDstn" to this list. The first two distributions are used when idiosyncratic agents are “born” in the model, specifying the distributions of initial capital and permanent income; the others are for drawing income shocks during the model.

The names in this list are used for two purposes:

1. When an AgentType instance’s reset() method is invoked, the distributions attribute tells HARK which distributions should be reset to their initial random state. This allows the same sequence of random values to be drawn on repeated simulation runs, which is important for many applications.

2. The legacy simulation system stores shock variable outcomes separately from other simulated data. For compatibility with the read_shocks functionality (in which the history of random draws can be drawn in advance or manually specified), shock_vars_ needs to name these variables.

State Variable Names

HARK’s legacy simulation system was in transition when development on it stopped, and it separately tracks state variables separately from control variables. As discussed below, the transition method for an AgentType subclass should return its output in the order of variables named in state_vars. The transition method does not need to return all state_vars, but it must return the ones it does in order.

For example, PerfForesightConsumerType and IndShockConsumerType both have state_vars of ["kNrm", "pLvl", "PlvlAgg", "bNrm", "mNrm", "aNrm", "aLvl"], and the transition method returns kNrm, pLvl, PlvlAgg, bNrm, mNrm. The other two variables, aNrm and aLvl, are computed later in the period.

Legacy Simulation System Methods

The original/legacy simulation system is being phased out of HARK, but is fully functional. The simulate() method calls the sim_one_period() method of AgentType on a loop, writing tracked variables to the history dictionary after each simulated period.

When sim_one_period is run, the following sub-methods are called in order:

• get_mortality : “Kills” and replaces some model agents with “newborns”.

• get_shocks or read_shocks_from_history : Fills in shock variables for this period.

• get_states : Computes information known at “decision-time” from prior state information and shock variables.

• get_controls : Evaluates the policy function using decision-time state variables.

• get_poststates : Compute variables that come after decision-time but still within this period.

Show Me How the Model Kills: sim_death and sim_birth

The get_mortality method of AgentType should not be overwritten by subclasses. Instead, an AgentType subclass should define methods called sim_death and sim_birth.

The sim_death method should return a Boolean array indicating which agents die between period \(t-1\) and period \(t\) and should be replaced with newborns, whatever that involves. If death and replacement is not a thing in your model, just return np.zeros(self.AgentCount, dtype=bool).

The sim_birth method should take one argument (other than self), a Boolean array of length AgentCount. The method should fill in beginning-of-period state values for any and all indices that are marked for death and replacement. These state values should be put in the appropriate entries of the state_now dictionary.

Additionally, sim_birth should reset t_age and t_cycle for newborns. The former represents how many periods each simulated agent has “lived for”, and the latter indicates which period of the “cycle” they are on. In most cases, this means setting them to zero for newborns.

The output of sim_death is stored in the attribute who_dies, which can be tracked like any other variable.

That’s So Random: get_shocks and read_shocks

Each AgentType subclass that wants to use the legacy simulation method should have a get_shocks method that draws any random variables for this period. The values should be written to entries in the self.shocks dictionary.

The legacy system has an option for pre-drawing all shocks. To do so, simply run the make_shock_history() method, which will fully populate the shock_history dictionary and set a flag called read_shocks, which is False by default. When read_shocks=True, the read_shocks_from_history method is called in place of get_shocks; as expected, it takes pre-drawn shocks from shock_history and passes them along as if they were freshly drawn.

Note that you do not need to run make_shock_history to use read_shocks=True. You can manually fill in the content of shock_history with whatever sequences of idiosyncratic values you’d like and manually set read_shocks to True. This can be useful for counterfactual experiments that move a population out of the long run ergodic distribution with some exogenous event.

NB: The new simulation system currently lacks read_shocks capability, which is one reason the legacy system still exists.

Getting to the Point: transition

The get_states() method simply calls the transition method and assigns its output to the state_now dictionary; it should not be overwritten by AgentType subclasses.

The transition method for an AgentType subclass should execute any model math that advances the agents from their beginning-of-period state to their decision-time state, probably using the results of the get_shocks step. As described above, it should return its outputs in the order listed in the state_vars class attribute.

I’m a Man of Action: get_controls

The get_controls() method for an AgentType should evaluate the policy or control functions (and any related functions) for the agents. This step probably involves some of the state variables listed in state_vars. Controls should be stored as entries of the controls dictionary attribute.

Wrapping Up: get_poststates

The get_poststates() method of an AgentType subclass is for calculating any model outcomes that occur after the control decision is made, but before the end of the period. This might involve combining decision-time states and control variables to find end-of-period states.

For example, in most consumption-saving models, end-of-period assets would be computed by get_poststates as \(a_t = m_t - c_t\).

All results should be stored as entries of the state_vars dictionary attribute.

Why Is This So Complicated?

A reasonable person might ask why we structured the original/legacy simulation system this way. Our intent was to reduce repetitive coding by allowing “child models” that build from “parent models” to inherit the simulation methods through class inheritance. The “child model” would replace only the simulation methods that actually differ from its parent.

For example, the KinkedRconsumerType inherits from IndShockConsumerType, with the only change being that the single interest factor Rfree is replaced by separate interest factors for borrowing and saving, Rboro and Rsave. All of the model mechanics during simulation are the same except for how \(\mathsf{R}\) is determined. The KinkedRconsumerType thus only replaces one small sub-routine (called get_Rfree) and otherwise defines no simulation methods.

More strongly, almost all of HARK’s consumption-saving models use the same sim_birth method– or at least call it as part of their extended sim_birth method. That is, most of our models begin with the agents drawing some initial permanent (or persistent) income level and some starting wealth.

As the set of models in HARK grew, however, the simulation methods became increasingly complicated. We had to build in features to “parent” models that were not used by them, just to accommodate things in “child” models. This can lead to confusion by a user who is investigating the code and finds bizarre trivial methods like PerfForesightConsumerType.get_Rfree(), which just returns self.Rfree.

Moreover, the way we coded these methods locked in the time (in)variant nature of model objects, because whether they are indexed by t_cycle in the simulation methods is hard-coded. This reduces user flexibility to change the specification.

I Don’t Want To and You Can’t Make Me

What if you want to make a new AgentType subclass, but don’t want to futz about with all of the methods described above? You have two main options:

1. Use HARK’s new simulation system by specifying the model in YAML format and using symulate rather than simulate.

2. Write an all-in-one sim_one_period method that handles all of the within-period mechanics, whatever that involves.

Both of these approaches are compatible with using track_vars to specify the set of idiosyncratic outcomes to be recorded in the history (or hystory) dictionary, and using simulate() to handle the main loop.

Extra Steps: pre_solve and post_solve

When the solve() method is called, HARK first runs the pre_solve method for that AgentType subclass. The default behavior of pre_solve doesn’t do much– just checks whether each attribute named in time-varying is actually a list (or other iterable, like an IndexDistribution).

Subclasses of AgentType can overwrite pre_solve to conduct whatever activities need to be accomplished just before the main solution loop. This most likely includes (re-)constructing solution_terminal in case any parameters have changed, or maybe even rebuilding all constructed objects by calling update().

Likewise, HARK runs the post_solve() method immediately after completing the model solution, but before exiting the call to solve(). By default, AgentType.post_solve() does nothing, so it must be overwritten by a subclass to do anything. This is useful for any “post-processing” steps.

In an infinite horizon model, there might be math that you don’t want to be executed on each iteration, but you do want evaluated for the final solution. For example, an IndShockConsumerType’s post_solve method calls the method calc_stable_points() if it is a standard infinite horizon problem (T_cycle=1) to find the “target” level of market resources.

Even more basically, post_solve might run convenience methods like unpack(), remapping attributes of the solution to be attributes of self for lazier access.
